Introduction
The phased array manual scanner (with track) is mainly used for phased array ultrasonic detection of the butt circumferential welds of pipes with a diameter of ≥200mm and flat plate butt welds. It is equipped with a probe holder and a roller encoder. A variety of different specifications of probe holders can be freely selected according to the detection needs, and the standard configured magnetic track is used for scanning guidance.
Performance Features
Scope of Application: Circumferential Direction: φ200mm~Flat Plate
Scanner Size: 144*97*125mm (Length*Width*Height)
Scanner Weight: 1.2KG
Encoder Step: 0.22mm/p
Environmental Resistance Level: IP65
Operating Temperature: -10℃-50℃
Applicable Accessories:
Coding Component Probe Holder Component(5L32-0.6) Probe Holder Component(5L32-1.0)
Probe Holder Component(Adjustable) Probe Holder Component(10L32-0.375)
