Water Immersion C-scan Ultrasonic Detection System

◆ Applicable to universities, research or testing organizations for transducer three-dimensional acoustic field related testing and experiments, the system interface is open, capable of secondary development to achieve a variety of research and testing

◆ Water immersion imaging scanning of special parts for non-destructive quality assessment

◆Adopt water immersion method, with the focusing probe, the workpiece is placed in the water tank, and the probe scans step by step.

not have

◆Multi-coordinate motion axes + water tank

◆1:1 accurate reproduction of the shape of the inspected workpiece and the size of defects

◆The zoom-in/zoom-out function clearly shows the edges of defects.

◆Adopting the water layer straightening function, eliminating the accumulated error caused by the control system traveling back and forth.

◆B, D scanning for easy viewing of arbitrary XY axis cross sections

◆ XYZ axis (can be customized):

X-axis travel: 400mm

Y-axis travel: 500mm

Z-axis travel: 450mm

Positioning accuracy: 0.1mm/m

Maximum travel speed: 50mm/s

Resolution: 0.1mm

Repeat positioning accuracy: 0.1mm

◆AB axis:

A-axis travel: ± 90°

B-axis travel: ± 45°

Movement speed: 10°/s

Motion accuracy: 0.1°

Resolution: 0.1°

Repeatability: 0.1°

◆ Powerful function, detection information recording function, can simultaneously have B-scan, C-scan and D-scan functions, able to real-time three-dimensional imaging of the transducer sound field.

◆High precision, 5-axis motion controller combined with high-precision linear module, X, Y, Z three-axis motion accuracy and repeatability up to 0.1mm, transducer pitch and rotary motion accuracy up to 0.1°.

◆The mechanical structure can be customized according to the requirements, or replace the 5-axis linear module as a manipulator hand. The software provides a variety of interface functions, which is convenient for secondary development and realizing a variety of scientific research tests.
