Introduction
PAUT manual scanner (chain type) is mainly used for ultrasonic detection of circumferential welds of pipes with a diameter of 500mm-1422mm. Equipped with 2 phased array probe holders and 2 TOFD probe holders. It is equipped with a suction cup track for scanning guidance, and an appropriate number of chain links can be selected for combined use according to the diameter specifications of the pipe being detected.
Performance Features
Scope of Application:φ500mm~φ1422mm
Scanner Size: 308*260*122mm(Length*Width*Height)
Scanner Weight: 7.8KG (1016 Pipe Configuration)
Encoder Step:0.12mm/p
Environmental Resistance Level:IP65
Operating Temperature:-10℃-50℃
Applicable Accessories:
Coding Component TOFD Probe Holder Phased Array Probe Holder
Standard Chain Link Scanning Chain Link Locking Mechanism
Roller Component Adaptation Link Adaptation Link
